The 63rd International Conference on Electron, Ion and Photon Beam Technology and Nanofabrication

The 25th EIPBN Bizarre/Beautiful Micrograph Contest is now closed. Please see all 2019 award winners and entries below.

The rules include the following:

  • Entries have to be of a single image taken with a microscope and should not be significantly altered.
  • There is no restriction with respect to the subject matter.
  • Electron and ion micrographs have to be black and white.

In 2019, 56 entries were submitted. The entries came from: Australia, Canada, The Netherlands, Spain,and the United States.

The judges were:

  • Shida Tan – Intel
  • Larry Muray – KLA
  • James Spallas – KLA

There were seven awards:

  • Grand Prize
  • Best Electron Micrograph
  • Best Ion Micrograph
  • Best Photon Micrograph
  • Most Phil-Harmonic Micrograph
  • Most Bizarre
  • 3Beamers Choice

There were also 8 honorable mention awards given.

To download a PDF with all 56 entries, click HERE


Grand Prize Micrograph

Title: Needles and the damage done

Description: Tilted Cross-Sectional SEM image of an Alignment Mark containing silicon structures in the etched areas, fabricated using Reactive-Ion Etching process

Horizontal Field Width: 70.6 µm

Instrument: FEI Nova NanoSEM

Submitted by: Maha Yusuf

Affiliation: Stanford University, CA


Best Electron Micrograph

Title: Micro Christmas Morning

Description: Poor adhesion during pattern transfer of metallic nanometer-thick features actually can give ideas for next Xmas?

Magnification (3″x4″ image): 10KX

Instrument: LEO 1530 Zeiss

 Submitted by: Gemma Rius

Affiliation: IMB-CNM-CSIC (Spain)


Best Ion Micrograph

Title: Beta Deathstar

Description: Sapphire sphere

Magnification (3″x4″ image): 1.2KX

Instrument: Zeiss He Ion microscope

Submitted by: Mark Mondol

Affiliation: MIT


Best Photon Micrograph

Title: Best Boson

Description: Far-field intensity produced by a diffractive optical element

Magnification: 40 (3″x4″ image)

Instrument: AndorZyla4.2 cMOS

Submitted by: Sergey Gorelick

Affiliation: Monash University, Australia


Most Phil-Harmonic Micrograph

Title: MicroTonal Xylophone

Description: Unknown vibration disturbed the waveguide writing by Nanoscribe3D, and was recorded in the resist.

Magnification (3″x4″ image): 1.8KX

Instrument: Hitachi 8230 SEM

Submitted by: JiangdongDeng (JD)

Affiliation: CNS at Harvard University


Most Bizarre Micrograph

Title: Merlot by the Femtoliter

Description: Polystyrene spheres on the photoresist pattern.

Magnification (3″x4″ image): 2 KX

Instrument: FEIVerios460

Submitted by: ZhirenLuo

Affiliation: North Carolina State University


3Beamers Choice

Title: MicroTonal Xylophone

Description: Unknown vibration disturbed the waveguide writing by Nanoscribe3D, and was recorded in the resist.

Magnification (3″x4″ image): 1.8KX

Instrument: Hitachi 8230 SEM

Submitted by: JiangdongDeng (JD)

Affiliation: CNS at Harvard University


Honorable Mention

Title: Imperial TIE fighters attacking an innocent Minnesotan micro-snowman

Description: Lamellas were ion-milled in fluorescent polysterenespheres

Magnification: 3.3KX (3″x4″ image)

Instrument: ThermoFisher Helios Ux-G4

Submitted by: Sergey Gorelick

Affiliation: Monash University, Australia


Title: Micro-Mango

Description: Microlensmilled in glass with a focused Xebeam. A 2D grating was then etched into its surface

Magnification: 5KX (3″x4″ image)

Instrument: ThermoFisherHelios Ux-G4

Submitted by: Sergey Gorelick

Affiliation: Monash University, Australia


Title: Larry’s Favorite (He likes puppies)

Description: When you lose control of your puppy…

Magnification: (3″x4″ image): 1.5KX

Instrument: FEI Verios460L

Submitted by: Yi-An Chen

Affiliation: North Carolina State University


Title: Pre-Brexit

Description: Europe map patterned using Electron beam induced deposition of Platinum. This is in 3D, the heights differ according to altitudes!

Magnification (3″x4″ image):   100KX

Instrument: Nova Nanolab650 SEM

Submitted by: Gaudhaman Jeevanandam

Affiliation: TU Delft, The Netherlands


Title: Into the Abyss

Description: The SU8 pattern.

Magnification (3″x4″ image):   2 KX

Instrument: FEIVerios460

Submitted by: ZhirenLuo

Affiliation: North Carolina State University


Title: Semiconductor Dunes

Description: High temperature treatment of semiconductor is always risky, yet it can provide beautiful landscapes of a micrometer world

Magnification (3″x4″ image): 25KX

Instrument: LEO 1530 Zeiss

Submitted by: Gemma Rius

Affiliation: IMB-CNM-CSIC (Spain)


Title: Thor’s E-Beam Lithography

Description: Copper / oxygen dihydride core-shell mm-scale nanotube slightly over-etched by naturally-occurring high energy beam of electrons

Magnification (3″x4″ image): 5X

Instrument: iPhone XS

Submitted by: James Owen

Affiliation: Zyvex Labs, Thunderstorm Alley, TX


Title: Tubing on the Mississippi somewhere

Description: A large river runs through a town filled with roads.

Magnification (3″x4″ image): 1.5KX

Instrument: TescanMIRA3

Submitted by: Lane Huston

Affiliation: Montana Technological University; Butte, Montana.
